Learn some basic game development skills in C++ with the library SDL (Simple DirectMedia Layer). In this course you learn to create a window and draw some rectangles. Later we build on top of that and design and implement a simple labyrinth game where the player has to go from one point of the screen to another end point. This course requires a fundamental knowledge of the programming language C++. Knowing C also helps.

Build a Game with SDL - Make a Labyrinth with C++ from Scratch - Beginner Tutorial

This lesson picks up from an initial exploration of Simple DirectMedia Layer (SDL), a library commonly used to develop video games.

The library header files for development were installed using apt in Ubuntu.

The function SDL_Init was used to initialize SDL. You can retrieve the errors emitted by SDL using the function SDL_GetError. You might find it useful to use the function SDL_Log for logging, the act of recording events that took place in the program.

One of the very first things you do is create a window to hold the game screen. That can be done with the SDL_CreateWindow function. Some of the arguments it takes are the title of the window, its position, and its dimensions.

Many of the functions from SDL return a pointer, so it is common to check if anything went wrong by comparing the return value to NULL, as was done with the result of SDL_CreateWindow.

The surface of the window can be retrieved using the function SDL_GetWindowSurface. You just need to pass in the pointer to the SDL_Window struct.

You can paint a filled rectangle on a surface using the SDL_FillRect function. It takes the pointer to the surface you want to paint, the pointer to the rectangle where you want to paint, and the color. You can pass NULL instead of SDL_Rect* to paint the whole surface. For the color, you can map to the required Uint32 using the function SDL_MapRGB.

The rectangle that was painted over the window surface will not appear to the user until the function SDL_UpdateWindowSurface is called.

A call to SDL_Delay was used to halt the execution of the program for a few milliseconds so the user could see something happen before it quit.

When you allocate resources such as an SDL_Window, it is important to remember to deallocate them. In this case, we used SDL_DestroyWindow to deallocate the memory used by the window and its surface.

Before the program quits, it is also important to make a call to close SDL. That is, using SDL_Quit().

Based on that initial exploration of libsdl, the lesson goes on to show how to paint a filled rectangle on a specific area of the window surface. An SDL_Rect is defined and its address is passed as the second argument to the SDL_FillRect function.

As part of more practice, concentric filled rectangles are painted at the center of the window surface.

A small square is used to represent the player on the screen. Its position is determined by an SDL_Rect structure. Its color is determined by a Uint32 variable whose value is mapped using a call to SDL_MapRGB().

We also learn to handle player input by polling events with the function SDL_PollEvent. Simply create a variable of type SDL_Event. Then pass the address of that variable to the SDL_PollEvent function. Keep calling that function as the condition of a loop, so long as the return value is not zero, meaning there is still some input to process.

We check if the event is a call to quit the program or if the event was a keyboard event where the key was pressed down.

The SDL_QUIT event type signals that we need to end the game loop and stop the execution of the program.

The SDL_KEYDOWN event type tells us we should look into player keyboard input. we check what key was pressed using the value from event.key.keysym.sym. For example, If the value is SDLK_RIGHT, it means the right-arrow key was pressed down. We then update the player position rectangle structure accordingly, based on that input signal.

We improve the player input with collision detection at the borders of the screen. That is, we cannot allow the player to walk outside the screen boundaries. That is done with simple if statement checks on the next position coordinate requested by the user.

By the end of the lesson, we have a screen with concentric filled rectangles. A small square, representing the player, can move across that screen with the keyboard arrow keys.


Exploring Game Development in C++ with SDL (libsdl / SDL2) – Beginner Tutorial from Scratch

fff2-01 Exploring Game Development in C++ with SDL (libsdl / SDL2) – Beginner Tutorial from Scratch

The goal of this lesson is to draw a game map with tiles that are loaded from a text file.

The screen can be segmented into small squares of length 32 pixels. If the width of the screen is 640px, then there will be 640px ÷ 32px = 20 tiles across. If the height of the screen is 480px, then there will be 480px ÷ 32px = 15 tiles down.

The game map can be stored in a text file using the following simple format: each line represents a row of tiles in the screen. To identify the type of tile for each cell, we use an integer number. The number for each cell is separated from the other by a space.

```
0 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 1 1 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 0 0
0 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
```

Each integer determines what kind of tile to be drawn. The number 0 represents the floor tile; the player can walk over it. The number 1 represents the wall tile; the player should not be able to walk on it.

As an example, consider this piece of the map, with 3 tiles across and 3 tiles down. The rendered game map image follows the data file:

```
0 1 1
0 0 0
1 0 0
```

![](/images/3by3gamemap.png)

After establishing the format for the game map, we create thefile GameMap.txt to store the tile identifiers.

In order for the program to draw the map, it needs to know what to draw. So we have to open the map file and read its contents.

We create the function loadGameMap to do that. It uses the fstream header to allow us to use the ifstream class. You can instantiate an object using the constructor, passing the name of the file as argument. After that, you check if the file is open, then proceed to iterate over the contents using the >> operator inside a loop:

```
while (gameMapFile >> tileId)
```

The variable on the left-hand side of the >> operator is the object bound to the file; the variable on the right holds the value of the next integer number read.

We store that value in an array of integers of size 20 × 15 = 300 elements. Each of those elements stores the id of the tile, so we know what kind to draw later, be it floor or wall.

After going through the data file, you should make sure to close it.

Once we load the identifiers for each tile into memory, we need to create a surface to paint them. We write the createGameMapSurface function to do that. It goes through each element in the array of tile identifiers and figures out where to paint each little square.

You can draw the tiles in many different ways. The lesson does it top to bottom, left to right. That is, it starts with the first row, then paints a tile in each column there. Next, it goes to the second row, then paints the tiles left to right. Repeat until there are no more rows to paint.

The function SDL_FillRect needs a pointer to a SDL_Rect to know what area of the surface to paint. We set the x and y members of the structure using the column and row position of the tile, respectively.

For a given row (of fixed y coordinate), the tiles are laid out along the x axis. So to get the coordinate for the tile at column index j, you multiply it by the width of the tile, 32 pixels:

```
rectangle.x = j * 32
```

To figure out the x coordinate, you do something similar, but involving the row index i, multiplying it by the height of the tile:

```
rectangle.y = i * 32
```

Note both i and j are counted starting from zero, not one. That is why I called them indices.

Once you have those two coordinates, you know exactly where to paint on the surface. But you do not yet know what kind of tile to paint. To figure that out, you look into the array of tile identifiers.

The lesson used a one-dimensional array to store the two-dimensional map. Because of that, we need a formula for the index of the element.

A two-dimensional array could have been used in this case. It could make development easier and there would not be a need for a formula here.

In any case, you can figure out the formula with this simple grid of 3x3:

![](/images/arrayelementindexmapping.png)

To get the element that is in the second row, second column, you consider:

For the column, we can get there if we add the column index j to the tile index: tiles[j]. The second column has index 1, so we have tiles[1].

That would give us the second column for the first row. To get to the second row, we need to add the total number of tiles for a single row. In the 3x3 example, it is 3. So we have 1 + 3 = 21, making the retrieval statement be tiles[4].

In general, the formula is

```
i * TILES_PER_ROW + j
```

For the case where the screen has a width of 640px, the tiles per row would be 20, if each tile has a width of 32px. The formula now being:

```
i * 20 + j
```

After getting the identifier for the tile, use a conditional such as an if statement to define the parameters for the tile that will be drawn. If the tile id is 0, make it have black color. If the tile id is 1, make it have white color.

We do it in a very simple way, but in practice you substitute the color statement for whatever configuration is necessary to render that tile. For example, the tile could be an image rendered out of a tile sheet and the statement would pick the correct clip from that tile sheet.


Loading the Game Map from a File and Painting it on the Window Surface – SDL Tutorial

fff2-02 Loading the Game Map from a File and Painting it on the Window Surface – SDL Tutorial

Mapping Coordinate to Corresponding Tile and Implementing Wall Collision – SDL2 Tutorial

fff2-03 Mapping Coordinate to Corresponding Tile and Implementing Wall Collision – SDL2 Tutorial

Defining the Entrance and Exit Position for the Labyrinth Game in SDL

fff2-04 Defining the Entrance and Exit Position for the Labyrinth Game in SDL

Improving the Codebase with Refactoring using Game class for Better Management

fff2-05 Improving the Codebase with Refactoring using Game class for Better Management

Wraping Up The Migration of Logic from Main to the Game Class

fff2-06 Wraping Up The Migration of Logic from Main to the Game Class

Compiling the Game in the Command Line with a Makefile and the make Command

fff2-07 Compiling the Game in the Command Line with a Makefile and the make Command
